Jinan cable bridge is mainly used for power transmission stage, cable and optical fiber support, protection and management. When the amount of cable and fiber wiring is large, it is easy to sag, so technicians think of using metal materials to make pipe gallery to protect the fiber and cable. However, the maintenance of traditional totally enclosed pipeline is complex and expensive. Therefore, open bridge is more and more popular in data center and IDC room.

　　在資料室中，常用的網橋有:網橋、電纜架、光纖通道。

　　In the reference room, the commonly used network bridges are: network bridge, cable rack, fibre channel.

　　顧名思義，橋是一種形狀類似于網狀結構的橋，也被稱為橋。網橋具有散熱性好、外形美觀等特點。但是，由于網橋的結構特點，后期需要對網橋進行維護和拉索，可以非常方便的進行施工，節省了大量的時間和人力成本。橋梁經過鍍鋅處理，還具有耐腐蝕、耐磨、壽命長等特點。

　　As the name suggests, a bridge is a kind of bridge with a shape similar to a network structure, also known as a bridge. The bridge has the characteristics of good heat dissipation and beautiful appearance. However, due to the structural characteristics of the bridge, the bridge needs to be maintained and stay cables in the later stage, which can be very convenient for construction, saving a lot of time and labor costs. After galvanizing treatment, the bridge has the characteristics of corrosion resistance, wear resistance and long service life.

　　1.的性能。網橋采用網狀結構，散熱效果更好，有效延長了電纜的使用壽命。鳳凰圖接線橋各焊點均采用歐洲標準焊接工藝，每個焊點可承載500kg，承載能力好。

　　1. Excellent performance. The network bridge adopts the mesh structure, which has better heat dissipation effect and effectively prolongs the service life of the cable. Each welding point of Fenghuang diagram junction bridge adopts European standard welding process, each welding point can bear 500kg, with good bearing capacity.

　　2.安裝方便，具有網絡結構，使橋梁的重量僅為傳統橋梁的五分之一。配件簡單，安裝靈活快捷。與傳統橋梁相比，節省了2/3的安裝時間。

　　2. It has convenient installation and network structure, making the weight of the bridge only one fifth of the traditional bridge. Simple accessories, flexible and quick installation. Compared with the traditional bridge, it saves 2 / 3 of the installation time.

　　3.在綜合布線系統中，可以更加靈活地使用升級和維護的電橋，以方便電橋的上下線路。在后期的維護中，電纜的升級也具有快速、的特點，節省了昂貴的雙重投資成本。

　　3. In the generic cabling system, the upgraded and maintained bridge can be used more flexibly to facilitate the up and down lines of the bridge. In the later period of maintenance, the upgrade of cable also has the characteristics of fast and safe, saving the expensive double investment cost.

　　4.美觀噴塑成型技術的應用，使橋梁外觀新穎、美觀、電阻小、電氣連續性好、電容量效應強。

　　4. The application of beautiful spray molding technology makes the bridge appearance novel, beautiful, small resistance, good electrical continuity and strong capacitance effect.

　　鋁合金電纜橋架與梯形相似，具有承載能力大、抗電磁干擾等特點。因此，鋁合金電纜架是高規格數據中心、機房等建筑中常用的電纜架。

　　Aluminum alloy cable tray is similar to trapezoid, with the characteristics of large bearing capacity and anti electromagnetic interference. Therefore, aluminum alloy cable rack is commonly used in high-specification data center, machine room and other buildings.

　　(1)鋁合金線框寬度可調，單、雙、多層、垂直線、水平線、任意組合。

　　(1) Aluminum alloy wire frame width adjustable, single, double, multi-layer, vertical line, horizontal line, any combination.

　　(2)鋁合金配線架平均承載能力大于300kg / m。

　　(2) The average bearing capacity of aluminum alloy distribution frame is more than 300kg / m.

　　(4)鋁合金線框總成，特殊零件，運輸方便。

　　(4) Aluminum alloy wire frame assembly, special parts, convenient transportation.

　　(5)鋁合金配線架可安裝在吊頂、地面支撐及沿墻安裝。

　　(5) Aluminum alloy distribution frame can be installed on the ceiling, ground support and along the wall.

　　數據中心使用光纖通道產品。在一定條件下，可有效利用布線空間，提高機房通風效率和整體美觀。

　　The data center uses fibre channel products. Under certain conditions, the wiring space can be effectively used to improve the ventilation efficiency and overall beauty of the machine room.

　　1.采用阻燃材料制成，表面光滑、美觀、大氣。

　　1. It is made of high-quality flame-retardant materials, with smooth, beautiful and atmospheric surface.

　　2.該產品重量輕，沖擊韌性高，機械性能好，可保護光纖不受損傷。

　　2. The product is light in weight, high in impact toughness and good in mechanical properties, which can protect the optical fiber from damage.

　　3.模塊化設計，插座靈活，光纖安裝快捷方便，節省大量施工時間。

　　3. Modular design, flexible socket, fast and convenient installation of optical fiber, saving a lot of construction time.

　　4.可與橋架、u型鋼線架、鋁合金線架搭配，并可固定在光纖槽的頂部或底部。整體設計統一、美觀、整潔。

　　4. It can be perfectly matched with the bridge, U-shaped steel wire frame and aluminum alloy wire frame, and can be fixed on the top or bottom of the optical fiber groove. The overall design is uniform, beautiful and tidy.

　　以上是濟南電纜橋架制造商為大家介紹的相關內容，想要了解更多內容，歡迎訪問網站：http://www.offroader.com.cn

　　The above is the relevant content introduced by Jinan cable tray manufacturer. For more information, please visit the website: http://www.offroader.com.cn
